RG186 LoRaWAN Gateway 868 Mhz
Item no. RG186-ND
Laird Sentrius RG186 LoRaWAN Gateway 868 Mhz, includes Wi-Fi, Bluetooth and Ethernet connectivity
VAT excluded
Specifications
- Weight
- 2000 g
Description
The Sentrius™ RG1xx LoRa-Enabled Gateway from Laird is the ultimate in secure, scalable, and robust LoRa solutions for end-to-end control of your private LoRaWAN network.
The Gateway offers LoRa coverage up to 16 km and pre-loaded LoRa Packet Forwarder software, perfect for highly flexible and scalable Internet of Things (IoT) networks.
Specifications
| Antenna Options | Channels | Connector Type | Frequency | Logical Interfaces | Max Transmit Power | Supported Operating Systems | Wireless Specifications |
|---|---|---|---|---|---|---|---|
| One 868 MHz antenna, two 2.4 /5 GHz antennas | 8 | Ethernet | LoRa: 863 - 870 MHz. Wi-Fi: 2.4 and 5 GHz. | Wired Ethernet - RJ45 Connector | +27 dBm | Embedded Linux, 4.x Kernel running on Atmel A5 Core @ 536 MHz | LoRaWAN, Bluetooth Version 4.0, and 802.11 a/b/g/n |
General
- Applications
Smart Metering and Remote Sensing, Industrial Automation / Monitoring and Control, Agricultural and Rural IoT / M2M Applications
- Chipset
LoRa: Semtech SX1301/1257. Bluetooth: Cambridge Silicon Radio CSR8811 A08. Wi-Fi: Qualcomm Atheros QCA6004
- Compliance
FCC, IC, CE (All Pending)
- Dimensions (L x W x H)
275.00 x 133.00 x 30.00 mm (10.83 x 5.24 x 1.18 in)
- Frequency
LoRa Frequencies: 863 - 870 MHz (EU)
Wi-Fi Frequencies: 2.4 and 5 GHz - Operating Systems Supported
Embedded Linux, 4.x Kernel
- Product Line
Sentrius Series - RG1xx LoRa-Enabled Gateway
- Protocol
Packet Network Forwarder Default support for The Things Network, Semtech IoT, Stream Communications, Loriot, Senet
- Security
Wi-Fi: Standards - WEP, WPA, WPA2. Encryption - WEP, TKIP. EAP Types - EAP-FAST, EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAP, PEAP-MSCHAPv2, PEAP-TLS, LEAP
Downloads
