RB4011 series: amazingly powerful routers with ten Gigabit ports, 10Gbps SFP+ interface and IPsec hardware acceleration.

The RB4011 uses a quad-core Cortex A15 CPU, as in our carrier-grade RB1100AHx4 unit. The unit features 1GB of RAM, can provide PoE output on port #10, and comes with a compact, professional-looking matte black metal enclosure. RB4011iGS + 5HacQ2HnD-IN (WiFi model) is dual-band, four-chain unit with a supported data rate up to 1733 Mbps in 5GHz. For legacy devices, the unit also has a dual-chain 2GHz wireless card installed in the miniPCI-e slot.

RB4011iGS + 5HacQ2HnD-IN (international) supports the 2412-2484MHz and 5150MHz-5875MHz frequency range (specific frequency range may be limited by country regulations).

Features

• ARM 32-bit architecture
• AL21400 CPU
• 4 core CPU
• CPU nominal frequency 1.4 GHz
• Dimensions 228 x 120 x 30 mm
• License level 5
• Operating system RouterOS
• RAM size 1 GB
• Storage size 512 MB
• Storage type NAND
• Tested ambient temperature from -40 ° C to 45 ° C



Powering

• PoE in Passive PoE
• PoE out Passive PoE up to 57V
• PoE in input Voltage 18-57 V
• Number of DC inputs 2 (DC jack, PoE-IN)
• DC jack input Voltage 12-57 V
• Maximum output per port (input > 30 V) 420 mA
• Maximum output per port (input < 30 v="" 600="" ma="" br="">Max total out (A) 600 mA
• Maximum power consumption 44 W
• Maximum power consumption without accessories 23 W

Wireless

• Number of 5 GHz wireless chains 4
• 5 GHz wireless standard 802.11ac MU-MIMO
• Antenna gain dBi for 5 GHz 3
• 5 GHz wireless chip model R11e-2HnD
• Number of 2.4 GHz wireless chains 2
• 2.4 GHz wireless standard 802.11b/g/n
• Antenna gain dBi for 2.4 GHz 3
• 2.4 GHz wireless chip model R11e-2HnD

Ethernet

• 10/100/1000 Ethernet ports 10

Fiber

• SFP+ ports 1
